Presented by George Knocke, CAE Applications Engineer
Date: Wednesday, August 6, 2025
Time: 11:00 AM - 12:00 PM EDT
Concepts NREC is developing a cycle analysis tool that incorporates our meanline modeling directly into the solver. In CYCALTM you can create a model of your cycle, complete with data imported from meanline turbomachinery designs. Drag and drop various components, change fluids, and calculate cycle performance characteristics based on our meanline models. Make decisions on working fluid, stage selection, and sizing with the combination of our meanline tools and a cycle code in one.
Content:
-
Drag and drop components to build your own cycle
-
Solve the cycle and review outputs
-
Meanline export, Cycal import
-
Case study — comparing two versions of a two stage chiller cycle
Can’t make the live event? Register anyway and receive the recording to view at your convenience.
